Mô tả
Model Name
HA236
LCD Panel Display size 23.6W
Brightness(Typical) 250cd/m2 (Typical)
NTSC 72%,±5%
Contrast(Typical) 1000:1 (Typical)
50,000,000:1 (high contrast ratio)
Resolution (H x V) 1920*1080/60Hz / 75HZ
Aspect Ratio 16:9
Response Time(Typical) GTG 8ms
View Angles LR,UD(CR>10) 178(H)/178(V) (CR>10)
Panel Surface Anti-glare
Display Colors 16.7M colors
PC Input Range Vertical Freq. 50~75Hz
Max. display frequency
(Resolution H*V/Fv) 1920 x 1080 /60 Hz
Interface Input 1 D-Sub x1
Input 2 HDMI x1
Input 3 DC in
Power Consumption(Typical) On: ≤30W
Standby<=0.5W, Off<=0.5W
Power Range AC 100-240V 50/60Hz
Power Mode
Indicator Light Power on : Blue (LED)
Power saving : Blue Flicker (LED)
Operating
Condition Temperature 0℃ ～ 40℃
Humidity 20% ~ 85%, non-condensing
Physical Dimension
(W*D*H) 538.5X340X165mm
Packing Dimension
(W*D*H) 647X157X505mm
Net Weight 3
Gross Weight 4.8
Tilt -5∘~ 15∘
Controls Front Control Menu, Bri (-), Vol(+) Input/Enter, Power
On Screen Display HKC 2015 new OSD
Color WARM,COOL, User Mode
Preset Mode PC, Movie, Game, ECO Modes
Accessory Power Cable NA
Adapter AC 100-240V 50/60Hz
Quick Start Guide(Paper) Yes
